Concept:Forces along the sides of a square act in two perpendicular directions, so resolve them into horizontal and vertical components and use Pythagoras.Explanation:Let AB be along the positive x-direction and BC along the positive y-direction.
Force along AB is 14N in the positive x-direction.Force along BC is 4N in the positive y-direction.Force along CD is 2N in the negative x-direction.Force along DA is 22N in the negative y-direction.Horizontal resultant: Rx=14−2=12N.Vertical resultant: Ry=4−22=4−2.828=1.172N.Magnitude of resultant: R=Rx2+Ry2.R=122+1.1722=144+1.3736=145.3736.∴R≈12.06N.Answer:12.06N (Option C).
