Concept:The output from Figure 1 is passed through a NOT gate, which inverts every bit of the value.Explanation:From the given inputs X and Y, the output Z obtained from the device in Figure 1 is 0111.This means the four results are 00→0, 01→1, 10→1, 11→1.Figure 2 is a NOT gate.A NOT gate changes each 0 to 1 and each 1 to 0.Therefore, Z=0111 becomes 0111=1000.Answer:D. 1000
