Concept:The device in Figure 2 is a NOT gate, and the logic gate in Figure 1 is an OR gate. So, first invert Y, then OR it with X to get Z.Explanation:The given input sequence for Y is 0101.Passing Y through the NOT gate gives:Y=1010Now find Z=X+Y for each row:X=0, Y=1⇒Z=1X=0, Y=0⇒Z=0X=1, Y=1⇒Z=1X=1, Y=0⇒Z=1So the resulting output sequence at Z is 1011.Answer:Option B: 1011
